Product Description

Breeze X1 is an ultra-slim tail light, just 28 mm deep, combining sleek, modern design with cutting-edge technology. Perfect for those looking to give their vehicle a sophisticated and contemporary look without compromising functionality. The tail light features three fully approved functions: rear light, brake light, and indicator light. The ultra-slim design and generous 2.5-meter cable length make this tail light easy to install.

Additionally, Breeze X1 comes with a built-in dynamic indicator function, allowing you to connect up to four lights per side. It can be mounted both horizontally and vertically, with both mounting options E-marked according to ECE R148.

Breeze X1 is available with either smoked lens or clear/transparent lens.


Specifications:

  • Smoked or clear lens
  • Multifunction: tail light, brake light and turn signal light
  • ECE R148 (approved for all three functions)
  • Total of 162 pcs LED
  • IP67 rated (waterproof and dustproof)
  • Voltage: 10-48V
  • Warranty: 36 months
  • Two screws and an instruction manual are included.

Measures:

  • Width: 110 mm
  • Height: 133 mm
  • Depth (total): 28 mm
  • Depth (recess): 10 mm
  • Cable: 2,5 m
  • CC: 115 mm

Synchronized Turn Signals: To ensure all turn signals on the same side flash simultaneously, connect all the yellow cables together on that side.

Dynamic turn signal: To achieve a dynamic turn signal, connect the yellow cable from the most inner light as in signal from the existing turn indicator signal. Then connect the green cable from the most inner light to the yellow cable on the light beside the first and continue this pattern from the inner to the outer lights.

Cable colors:

  • Black - earth (ground)
  • White - tail light
  • Red - brake light
  • Yellow - indicator (input signal)
  • Green - output indicator signal to the next light
