If you like to be seen, Ledson OptoLine D position light / side marker is just right for you! Equipped with a reflex and fiber optic LED with two nicely solid lines gives a delicious, modern impression. E-marked side marker or position light with approved reflex, waterproof and works for both 12 and 24V. Has the same CC dimensions of 90mm as Talmu and Hella.

3 meter cable, screws for mounting included.

Characteristics:

• Orange E-marked: ECE R3, R91 -
• White and red E-marked: ECE R3, R148
• Godkända som positionsljus eller sidomarkering med godkänd reflex
• EMC secured: ECE R10
• Fiber optics with orange, white or red light (select your color)
• 2 x LED
• IP67 rated (water / dust tight)
• Voltage: 12-24V
• Power consumption: 0,6W (12V), 1,4W (24V)
• Operating temperature: -40°C till 65°C

Dimensions & weight:

• Length: 111 mm
• Height: 51 mm
• Depth: 18 mm
• Cable length: 3 meter
• Weight: 48 gram
• Hole distance: 90 mm (cc)

Side marker cable colors:

• Black: power (+)
• White: ground (-)

Available as:

• White (part number 360521)
• Red (part number 360522)
• Orange (part number 360523)
