LEDSON Pollux9+ Generation 3: More powerful and smarter than ever
Pollux9+ Generation 3 is an LED auxiliary light with pulse-controlled powerboost from Ledson, developed to provide very high light intensity, long range and flexible light control in varying driving conditions. With an output of 120 W and pulse-controlled powerboost function, strong performance is combined with adjustable light intensity when the need is greatest. The robust design is developed for long-term use in demanding environments and maintained performance over time.
Pulse-controlled powerboost
Pollux9+ Generation 3 Strobe is equipped with Ledson powerboost, an extra power mode that provides maximum brightness when needed. The mode is easily activated via the high beam lever, allowing quick adjustment of the auxiliary light output. The new generation of powerboost is controlled via the light switch (the high beam lever strobees) according to the steps specified in the instructions. The product is delivered in E-approved mode and activation of the powerboost mode is done according to the accompanying instructions.
TIR reflectors
Pollux9+ Generation 3 uses TIR (Total Inner Reflection) reflectors, which means that all light is effectively reflected and directed before it leaves the reflector. Spill light, i.e. light that would otherwise leave the luminaire unfocused and without any real benefit, is minimised. Unlike traditional reflectors, which only direct most of the light, Pollux9+ utilises TIR technology to maximise the usable light.
Selectable beam pattern: Driving or spot
Pollux9+ Generation 3 is available with two different beam patterns. The driving beam version provides a balanced beam pattern that complements the vehicle's regular headlights. The spot beam version provides a more concentrated beam of light that effectively illuminates the road far ahead of the vehicle.
Strobe light
The auxiliary light offers five different strobe light patterns that can be synchronised between Pollux9+ Generation 3 units. The units can be connected so that the same strobe light pattern is synchronised across all connected auxiliary lights, or divided into two groups for alternating strobe light patterns. Available strobe light patterns are single strobe (ECE R65 approved), double strobe, triple strobe, quadruple strobe and continuous hyper strobe.
Mounting on the vehicle
Pollux9+ Generation 3 can be mounted discreetly and securely with a number plate holder or tube bracket. Available accessories offer several mounting options. For connection, we recommend Ledson Connect 12 V or DT relay set 24 V with original connection to the vehicle. This allows the auxiliary light to be controlled via a separate button or connected to the high beam so that the auxiliary light automatically turns on and off with the high beam. The solution includes a fuse between the auxiliary light and the battery to protect the battery and other equipment. When using XBB, it can be connected directly to the Connect. Detailed installation instructions are included with the DT relay.
As a complementary accessory, there is a quick connector for the relay set with ready-made connectors, which allows installation without damaging the car's original wiring and without the need for a power tap, for quick and easy installation.
Included
The delivery includes Ledson Pollux9+ Generation 3 LED auxiliary light, bolts and screws for mounting with one or two mounting points, DT connector (6-pin) intended to be supplemented with Ledson Connect, and installation instructions.
Installation instructions for cables
The cables are colour-coded as follows: red cable for auxiliary light (+), black cable for auxiliary light/Position light (- ground), white cable for position light (+) white light, yellow cable for position light (+) yellow-orange light, green cable for strobe light (+), blue cable for synchronisation and pattern (+) and brown cable for alternating function (+).
Please note: The DT connector must not be cut, as this increases the risk of moisture damage and will invalidate the warranty.
